VLSI Lab 4 Verilog MegaWizard IP Generator (Compiled on Quartus II v20.1) - 2024 simplified version



VLSI Lab 4, EIE, 2024 version


Laboratory Objectives

The objectives of this laboratory are:

·        Understand the use of Altera’s MegaWizard IP generator: (https://ftp.intel.com/Public/Pub/fpgaup/pub/Teaching_Materials/current/Tutorials/Verilog/Using_Library_Modules.pdf)

·        How to specify synthesis options and their impact

·        Understand the impact of placement on the design quality using Pin Planner

Project files are archieved in Google drive:


Top entry sqrt.v file:

// ----- EIE Lab 4
// -----     https://vlsiorfpgadesign.blogspot.com/     ----- //
// Using IP core altsyncram
module sqrt (
sqrt_in,
sqrt_out);
parameter width = 4;  // # bits
input [width-1:0] sqrt_in;
output [width:0] sqrt_out;
wire [width/2-1:0] q_sig;    // quotient
wire [width/2:0] remainder_sig; // rmainder
sqrt_ip U1_sqrt_inst (
     .radical(sqrt_in),
     .q(q_sig),
      .remainder(remainder_sig));

assign sqrt_out = {q_sig[width/2-1:0], remainder_sig[width/2:0]};
endmodule

// -------------------------------------- //

Simulation results:




(Click to enlarge the picture)
